Open RegiónAñoModeloCódigo de modelo Detalles
General 2018 G80 16 B1S4J6A1J
Catalog: GENESIS202602 Model: B1S4J6A1J Model Year: 2019 Engine Number: G6DNJA126609 Transmission Number: WAJARU014529 Destination: MES Nation: SAUDI ARABIA Plant: K3 Exterior Color: CARBON METAL Interior Color: CAMEL ORANGE Drive Type: DRIVE TYPE - LHD Weather Type: WEATHER - THE TROPICAL ZONE Body Type: SEDAN - 4DR 5P Engine Capacity: 3800 CC - LAMBDA 2 Engine Type: DOHC - GDI Fuel Type: GASOLINE - UNLEADED Transaxle: AUTO - 8 SPEED 2WD Build Date: 2018-11-17 Nation Code: D15 Area: K3 Drive Type: L Weather Type: 1 Order Number: E1811R021D15A Vehicle Factory: 084 Full Specification Code: D15AB1S4J6A1J GA1113 Exterior Color Code: N5M Interior Color Code: NNR Engine Mip Code: AP25 Transmission Mip Code: ZB12 Vin Tag: 1 Model Year Code: 16 Catalog Information: (S4) SEDAN - 4DR 5P,(J6) 3800 CC - LAMBDA 2,(A) DOHC - GDI,(1) GASOLINE - UNLEADED,(J) AUTO - 8 SPEED 2WD,(L) DRIVE TYPE - LHD,(1) WEATHER - THE TROPICAL ZONE Region: OTHER Native Region: MES

Genesis G80 16 2018 — Engine & Transaxle Mounting [3800 CC - Lambda 2]

Ver los diagramas del vehículo

Piezas de repuesto

Número de parteDescripciónPNCCantidad
21819B1200 BOLT 6
Production:2015-11-01 – …
1151306146K STUD 1
Production:2015-11-01 – …
1339608007K NUT 2
Production:2015-11-01 – …
1339612007K NUT 1
Production:2015-11-01 – …
1351012006K WASHER - [PLAIN] 4
Production:2015-11-01 – …
1360212006K WASHER - SPRING 4
Production:2015-11-01 – …
21826B1100 BRACKET - ENGINE SUPPORT, LH 1
Production:2015-11-01 – …
21825B1100 BRACKET - ENGINE SUPPORT, RH 1
Production:2015-11-01 – …
21812B1120 INSULATOR - HYDRAULIC, LH 1
Production:2015-11-01 – …
21812B1170 INSULATOR - HYDRAULIC, RH 1
Production:2015-11-01 – …
218593M300 BOLT - WASHER 21815E 1
Production:2015-11-01 – …
21819B1000 BOLT 12
Production:2015-11-01 – …
21830B1100 BRACKET ASSY - TRANSMISSION MOUNTING 1
Production:2015-11-01 – …
21893D2000 BOLT - WASHER ASSY 6
Production:2015-12-25 – …
28785B1500 SUPPORT ASSY - HANGER 1
Production:2015-11-01 – …
287613M300 HANGER - EXHAUST PIPE 2
Production:2015-11-01 – …
28785B1600 SUPPORT - HANGER 1
Production:2015-11-01 – …
493293M000 NUT 2
Production:2015-11-01 – …
554193M100 BOLT 2
Production:2015-11-01 – …
55419B1000 BOLT 2
Production:2015-11-01 – …
841813L000 TAPE - BLANKING HOLE 4
Production:2015-11-01 – …

Diagrama

21 piezas
Genesis G80 16 2018 — Engine & Transaxle Mounting [3800 CC - Lambda 2]
