  • 3147060081 Toyota CYLINDER ASSY, CLUTCH RELEASE

3147060081 Toyota CYLINDER ASSY, CLUTCH RELEASE, Price: 65.84$, Weight: 0.603kg

    • Make Number Name Availability Weight, kg Ship in, Days Price

    Toyota

    3147060081

    CYLINDER ASSY, CLUTCH RELEASE

    		 1

    0.603

    2-3

    65.84$


    Originals

    Make Number Name Availability Weight, kg Processing, days Price
    Napco
    3147060081
    COC 31470-60081-NAP TOYOTA LANDCRUISER
    		31
    0.693
    4-5
    7.30$

    Axcel
    3147060081
    COC/ 31470-60081-AXL
    		25
    0.693
    2-3
    8.40$

    BGF
    3147060081
    CYLINDER KIT
    		15
    0.693
    4-5
    13.12$

    FIC
    3147060081
    C.O.C ASSY - FO-1062
    		0
    0.693
    4-5
    10.28$
    		 Not Available

    Substitutions

    Make Number Name Availability Weight, kg Processing, days Price
    FIC
    FO1062
    C.O.C. ASSY 2F FJ40/60 81-84
    		0
    1.151
    4-5
    12.47$
    		 Not Available
    BGF
    3147060080
    CLUTCH OPERATING CYLINDER ASSY
    		0
    0.693
    4-5
    12.13$
    		 Not Available
    AISIN
    CRT019
    CLUTCH RELEASE CYLINDER TO 31470-60081 LAND CRUISER 198008-198604 AISIN
    		0
    0.693
    4-5
    33.51$
    		 Not Available

    Compatibility

    DescriptionModelOptionsProd PeriodDiagram
    BJ4#,HJ47,FJ4#FJ45RP-K3Building Condition: INCOMPLETE VEHICLES (CHASSIS & CAB); Driver's Position: RIGHT-HAND DRIVE VEHICLES; Body: PICKUP; Gear Shift Type: MTM, 4-SPEED FLOOR SHIFT; Engine: (2F) 4200CC; Destination: GENERAL COUNTRIES08.1980 - 06.1985 View
    DescriptionModelOptionsProd PeriodDiagram
    BJ6#,FJ6#,HJ6#FJ61V-KCH4ATM,MTM: MANUAL TRANSMISSION; Building Condition: FIER TRUCK; Roof: STANDARD ROOF; Body: STATION WAGON; Fuel Induction: CARBURETOR SYSTEM; Gear Shift Type: MTM, 4-SPEED FLOOR SHIFT; Engine: (2F) 4200CC10.1982 - 11.1984 View

    Hydraulic Clutch Release Cylinder for Toyota 4x4

    Why this part is needed

    This hydraulic unit disengages the clutch smoothly, giving clean gear changes, steady pedal feel, and long clutch life. In heavy SUVs and off‑road use, it keeps shifts precise under heat, dust, and load. A healthy release cylinder means confident starts on hills and no gear crunching.

    How it works ⚙️

    When you press the pedal, the master cylinder sends fluid pressure to this cylinder. Inside, a piston and seals convert that pressure into linear movement. The pushrod drives the fork and release bearing, separating the disc from the flywheel. A tight bore, return spring, and dust boot keep motion accurate; the bleeder lets you purge air for a firm pedal.

    What happens if it fails

    Signs include soft/spongy pedal, hard shifting, grinding when selecting reverse, and wetness or cracking at the boot . Ignoring it causes clutch drag, overheated friction material, worn synchros, and can leave you stranded. Replace promptly and flush fresh DOT 3/4 fluid; inspect hose and fork for wear.

    Install tips ️

    Bolt to bellhousing, connect line, torque to spec, then bleed until a consistent, high pedal. Use quality fluid and keep the system clean.

    Compatibility

    • Land Cruiser
    • Land Cruiser Van
