General 2023 GRANVIA HYBRID AXLH40L-QNXXHC
Catalog: TOYOTA202608 Engine: 2500CC 16-VALVE DOHC Transmission Description: CONTINUOUSLY VARIABLE TRANSMISSION Steering Description: LEFT-HAND DRIVE VEHICLES Destination Description: CHINA Color Code: 089 Trim Code: LA10 Production: 202211-999999 Model Short: AXLH40L-QNXXHC Region: OTHER Native Region: GR

Toyota Granvia-Hybrid 2023 — Front Fender Apron & Dash Panel

Browse vehicle diagrams

Spare Parts

Part numberDescriptionPNCQty
16592-F0170 GUIDE, RADIATOR AIR, NO.3 1
Note:A25..AXLH4#..E,P,V,W,X Production:2022-11 – …
16593-F0500 GUIDE, RADIATOR AIR, NO.1 RH 1
Note:A25..AXLH4#..E,P,V,W,X Production:2022-11 – …
16594-F0140 GUIDE, RADIATOR AIR, NO.2 1
Note:A25..AXLH4#..E,P,V,W,X Production:2022-11 – …
16595-F0520 GUIDE, RADIATOR AIR, NO.1 LH 1
Note:A25..AXLH4#..E,P,V,W,X Production:2022-11 – …
53381-08070 SEAL, HOOD TO RADIATOR SUPPORT 1
Note:AXLH4#..E,P,V,W,X Production:2022-11 – …
53285-08040 GUARD, COOL AIR INTAKE 1
Note:AXLH4#..E,P,V,W,X Production:2022-11 – …
53295-08050 SEAL, COOL AIR INTAKE DUCT 1
Note:AXLH4#..E,P,V,W,X Production:2022-11 – …
90467-C0041 standard —
Replacements:90467-07214 (fitment: unknown)
90467-C0051 standard —

Diagram

9 parts
Toyota Granvia-Hybrid 2023 — Front Fender Apron & Dash Panel
