General 2021 HILUX DOUBLE CAB GGN125L-DTTHKV
Catalog: TOYOTA202608 Engine: 4000CC 24-VALVE DOHC EFI Transmission Description: AUTOMATIC TRANSMISSION, MTM, 6-SPEED FLOOR SHIFT Steering Description: LEFT-HAND DRIVE VEHICLES Destination Description: GULF CORPORATION COUNCIL Color Code: 070 Trim Code: FR21 Production: 202108-202208 Model Short: GGN125L-DTTHKV Region: OTHER Native Region: GR

Toyota HILUX-DOUBLE-CAB 2021 — Switch & Relay & Computer

Browse vehicle diagrams

Spare Parts

Part numberDescriptionPNCQty
89467-71110 SENSOR, AIR FUEL RATIO 2
Note:GGN125 Production:2021-08 – 2021-11
89465-0K170 SENSOR, OXYGEN NO.2 1
Note:GGN125..GCC Production:2021-08 – 2022-07
83530-28020 SWITCH ASSY, OIL PRESSURE (FOR ENGINE) 1
Note:GGN125,TGN120,121,126,136..THP Production:2021-08 – 2022-07 Spec:DENSO
83530-60020 SWITCH ASSY, OIL PRESSURE (FOR ENGINE) 1
Note:GGN125,TGN120,121,126,136..THP Production:2021-08 – 2022-07 Spec:YAZAKI
89615-20090 SENSOR, KNOCK CONTROL 2
Note:GGN125..GCC Production:2021-08 – 2022-07
89465-0K180 SENSOR, OXYGEN 1
Note:GGN125..GCC Production:2021-08 – 2022-07
82715-71180 standard —
90119-T0134 standard —
Replacements:91671-80612 (fitment: unknown)
91551-80830 standard —
82715-71210 standard —

Diagram

10 parts
Toyota HILUX-DOUBLE-CAB 2021 — Switch & Relay & Computer
