Open RegionYearModelModelCode Details
General 2023 VIOS YARIS NSP151L-FHXGKR
Catalog: TOYOTA202608 Engine: 1500CC 16-VALVE DOHC EFI Transmission Description: CONTINUOUSLY VARIABLE TRANSMISSION Steering Description: LEFT-HAND DRIVE VEHICLES Destination Description: FOR TAIWAN Doors Description: 5-DOOR Color Code: 1G3 Trim Code: EB25 Production: 202101-999999 Model Short: NSP151L-FHXGKR Region: OTHER Native Region: GR

Toyota Vios-Yaris 2023 — Switch & Relay & Computer

Browse vehicle diagrams

Spare Parts

Part numberDescriptionPNCQty
84540-52070 SWITCH ASSY, NEUTRAL START 1
Note:NSP151..5D Production:2021-01 – 2023-06 Fitment:Matches · model
84540-52070 SWITCH ASSY, NEUTRAL START 1
Note:NSP151..D Production:2021-01 – 2024-07 Fitment:Matches · model
84540-52070 SWITCH ASSY, NEUTRAL START 1
Note:NSP151..4D..(R,V) Production:2021-01 – … Fitment:Matches · model
89465-52740 SENSOR, OXYGEN 1
Note:NSP151..5D Production:2021-01 – 2023-06 Fitment:Matches · model
89465-52740 SENSOR, OXYGEN 1
Note:NSP151..D Production:2021-01 – 2024-07 Fitment:Matches · model
89465-52740 SENSOR, OXYGEN 1
Note:NSP151..4D..(R,V) Production:2021-01 – … Fitment:Matches · model
89467-30050 SENSOR, AIR FUEL RATIO 1
Note:NSP151..5D Production:2021-01 – 2023-06 Fitment:Matches · model
89467-30050 SENSOR, AIR FUEL RATIO 1
Note:NSP151..D Production:2021-01 – 2024-07 Fitment:Matches · model
89467-30050 SENSOR, AIR FUEL RATIO 1
Note:NSP151..4D..(R,V) Production:2021-01 – … Fitment:Matches · model
83530-28020 SWITCH ASSY, OIL PRESSURE (FOR ENGINE) 1
Note:NSP151..5D Production:2021-01 – 2023-06 Spec:DENSO Fitment:Matches · model
83530-60020 SWITCH ASSY, OIL PRESSURE (FOR ENGINE) 1
Note:NSP151..5D Production:2021-01 – 2023-06 Spec:YAZAKI Fitment:Matches · model
83530-28020 SWITCH ASSY, OIL PRESSURE (FOR ENGINE) 1
Note:NSP151..D Production:2021-01 – 2024-07 Spec:DENSO Fitment:Matches · model
83530-60020 SWITCH ASSY, OIL PRESSURE (FOR ENGINE) 1
Note:NSP151..D Production:2021-01 – 2024-07 Spec:YAZAKI Fitment:Matches · model
83530-28020 SWITCH ASSY, OIL PRESSURE (FOR ENGINE) 1
Note:NSP151..4D..(R,V) Production:2021-01 – … Spec:DENSO Fitment:Matches · model
83530-60020 SWITCH ASSY, OIL PRESSURE (FOR ENGINE) 1
Note:NSP151..4D..(R,V) Production:2021-01 – … Spec:YAZAKI Fitment:Matches · model
89615-20090 SENSOR, KNOCK CONTROL 1
Note:NSP151..5D Production:2021-01 – 2023-06 Fitment:Matches · model
89615-20090 SENSOR, KNOCK CONTROL 1
Note:NSP151..D Production:2021-01 – 2024-07 Fitment:Matches · model
89615-20090 SENSOR, KNOCK CONTROL 1
Note:NSP151..4D..(R,V) Production:2021-01 – … Fitment:Matches · model
82715-5C360 BRACKET,WIRING HARNESS CLAMP 1
Note:NSP151..5D Production:2021-01 – 2023-06 Fitment:Matches · model
82715-5C360 BRACKET,WIRING HARNESS CLAMP 1
Note:NSP151..D Production:2021-01 – 2024-07 Fitment:Matches · model
82715-5C360 BRACKET,WIRING HARNESS CLAMP 1
Note:NSP151..4D..(R,V) Production:2021-01 – … Fitment:Matches · model
82715-12S40 BRACKET, EXHAUST SENSOR CLAMP 1
Note:NSP151..5D Production:2021-01 – 2023-06 Fitment:Matches · model
82715-12S40 BRACKET, EXHAUST SENSOR CLAMP 1
Note:NSP151..D Production:2021-01 – 2024-07 Fitment:Matches · model
82715-12S40 BRACKET, EXHAUST SENSOR CLAMP 1
Note:NSP151..4D..(R,V) Production:2021-01 – … Fitment:Matches · model
91651-40620 standard —
Fitment:Matches · model
91671-80816 standard —
Fitment:Matches · model
90119-T0237 standard —
Replacements:91671-80816 (fitment: unknown) Fitment:Matches · model
90105-T0156 standard —
Replacements:91551-80835 (fitment: unknown) Fitment:Matches · model
90105-T0178 standard —
Replacements:91553-81014 (fitment: unknown) Fitment:Matches · model

Diagram

29 parts
Toyota Vios-Yaris 2023 — Switch & Relay & Computer
