Open RegionYearModelModelCode Details
General 2018 FORTUNER GUN165L-SDFLHU
Catalog: TOYOTA202608 Engine: 2400CC DIESEL TURBO Transmission Description: MANUAL TRANSMISSION, MTM, 6-SPEED FLOOR SHIFT Body Description: INDONESIA PRODUCED SUV WAGON Steering Description: LEFT-HAND DRIVE VEHICLES Destination Description: VIETNAM Color Code: 1D6 Trim Code: FN41 Production: 201601-202007 Model Short: GUN165L-SDFLHU Region: OTHER Native Region: GR

Toyota Fortuner 2018 — Switch & Relay & Computer

Browse vehicle diagrams

Spare Parts

Part numberDescriptionPNCQty
84210-71050 SWITCH ASSY, BACK-UP LAMP 1
Note:GUN15#,16#,KUN156,165..6F Production:2015-07 – 2020-12
— Part does not apply to this vehicle configuration. 84540 —
33576-0K010 BRACKET, BACK-UP LAMP SWITCH, NO.1 1
Note:GUN15#,16#,KUN156,165..6F Production:2015-07 – 2020-12 Spec:TYPE A:REFER 33-01
33576-0K040 BRACKET, BACK-UP LAMP SWITCH, NO.1 1
Note:GUN15#,16#,KUN156,165..6F Production:2015-07 – 2020-12 Spec:TYPE B:REFER 33-01
33576-0K020 BRACKET, BACK-UP LAMP SWITCH, NO.2 1
Note:GUN15#,16#,KUN156,165..6F Production:2015-07 – 2020-12 Spec:TYPE A:REFER 33-01
33576-0K050 BRACKET, BACK-UP LAMP SWITCH, NO.2 1
Note:GUN15#,16#,KUN156,165..6F Production:2015-07 – 2020-12 Spec:TYPE B:REFER 33-01
33576-0K030 BRACKET, BACK-UP LAMP SWITCH, NO.3 1
Note:GUN15#,16#,KUN156,165..6F Production:2015-07 – 2020-12 Spec:TYPE A:REFER 33-01
33576-0K060 BRACKET, BACK-UP LAMP SWITCH, NO.3 1
Note:GUN15#,16#,KUN156,165..6F Production:2015-07 – 2020-12 Spec:TYPE B:REFER 33-01
90119-08C62 standard —
90105-T0070 standard —
Replacements:91551-80614 (fitment: unknown)
90430-18008 standard —
82715-71120 standard —
82715-0K680 standard —
Replacements:82715-71120 (fitment: unknown)

Diagram

12 parts
